Krona Koblenz Kombi Hybrid K1019

Clear
SKU: K.1019 Categories: ,

Description

Krona Koblenz Kombi Hybrid K1019

Sold : each

Availability

3-6 weeks from date of order

Product Information

Usage: Commercial and residential doorsets

Weight Rating

40kg – 2 Hinges

Material

Steel / POM C / Zamk

Minimum Door Thickness

32 mm

Additional Information

A concealed hinge made of highly resistant steel for flush doors with wooden, steel and aluminium frames. Load capapcity up to 40kg, 180 opening angle with the minimum door thickness of 32mm. Wear-resistant bushings, lubrications/maintenance not required, reseversible for the right and left handle doors.

3D-adjustable, all adjustments are independent, tool aided and self loading.

Adjustments: horizontal +3,0/-1,5mm, vertical =+/-2,5mm, Planar +/- 1,0mm

Cover caps are supplied with this product
