Krona Koblenz Kubica Adjustable Concealed Multiaxial Hinges K2780

Clear
SKU: K.2780 Categories: ,

Description

Krona Koblenz Kubica Adjustable Concealed Multiaxial Hinges K2780

Sold : each

Availability

3-6 weeks from date of order

Product Information

Usage: Commercial and residential doorsets

Weight Rating

80kg – 2 Hinges

Material

Steel / Zamak

Mininimum Door Thickness

35mm

Maximum Door Thickness

45mm

Additional Information

A concealed hinge made of highly resistant steel for flush doors with wooden, steel and aluminium frame. Concealed hinge for internal flush to wall doors. Reversible panel. Can be used with cladding on the door and frame construction.  Self-centring on door leaves 35-45 mm thick. Load capacity up to 80kg with 2 hinges fitted.  180 degree opening angle with the minimumdoor thickness of 35mm.

3D-adjustable, all adjustments are independent, tool aided and self loading.

Adjustments: Side +3mm/-1.5mm, height +/-2,5mm, compression +/- 1,0mm

Cover caps are supplied with this product

Suitable for use with door closer
