Product Information

The Frelan J9504 Ball Bearing Hinge is a practical 76mm hinge with a compact profile for internal doors. Built from Grade 201 stainless steel with a satin finish, it is FD30 fire rated and provides durability for residential and commercial interiors.

• Type: Ball Bearing Hinge
• Material Grade: 201 Stainless Steel
• Max Door Weight: 40KG (3 Hinges)
• BS EN 1935
• Fire Rating: FD30
• Hinge Grade: 7
• Corrosion Grade: 4
• Mechanical Warranty: 10 Years
• Use: Internal : Residential / Commercial
• UKCA / CE

Dimensions

• Height: 76mm
• Width: 50mm
• Knuckle: 10mm
• Thickness: 2mm

Note: Fire Rated when used with intumescent hinge pads.
